| Nominal Impedance |
|
4 Ohms |
| DC resistance, |
|
Re 3.1 Ohms |
| Voice coil inductance, |
|
Le 0.25 mH |
| Effective piston area, |
|
Sd 50.0 cm2 |
| Voice coil diameter |
|
25.4 mm |
| Voice coil height |
|
15 mm |
| Air gap height |
|
5 mm |
| Linear coil travel |
|
(p-p) 10mm |
| Magnetic Flux Density |
|
1.03 T |
| Magnet weight |
|
400g |
|
|
| Moving mass incl. air, |
|
Mms 6.1 g |
| Free air resonance, |
|
Fs 52.5 Hz |
| Sensitivity (2.83 V / 1 m) |
|
87.0 dB |
| Mechanical Q-factor |
|
Qms 5.0 |
| Electrical Q-factor |
|
Qes 0.33 |
| Total Q-factor |
|
Qts 0.31 |
| VAS |
|
5.3L |
| Compliance |
|
Cms 1.50 mm/N |
| Force factor |
|
Bl 4.35 Tm |
| Rated power handling* |
|
30 W |
|
